Грузовой вагон ( )| Таблицы данных | Фотографии | Производитель. Часть # | Акции | Цены | А | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
|
PJD16N06A-AU_L2_000A160V N-CHANNEL ENHANCEMENT MODE M |
3261 | 0.78 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 4.4A (Ta), 16A (Tc) | 4.5V, 10V | 50mOhm @ 8A, 10V | 2.5V @ 250µA | 14 nC @ 10 V | ±20V | 815 pF @ 15 V | - | 2.4W (Ta), 32.6W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
| |
|
PJD45N06A_L2_0000160V N-CHANNEL ENHANCEMENT MODE M |
3972 | 0.78 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 45A (Tc) | 4.5V, 10V | 12mOhm @ 20A, 10V | 2.5V @ 250µA | 39 nC @ 10 V | ±20V | 2256 pF @ 25 V | - | 63W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
| |
|
PJQ5443_R2_0000140V P-CHANNEL ENHANCEMENT MODE M |
2079 | 0.78 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | P-Channel | MOSFET (Metal Oxide) | 40 V | 9A (Ta), 50A (Tc) | 4.5V, 10V | 12mOhm @ 10A, 10V | 2.5V @ 250µA | 23 nC @ 4.5 V | ±20V | 2767 pF @ 25 V | - | 2W (Ta), 63W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
DMN2009LSS-13MOSFET N-CH 20V 12A 8SOP |
2480 | 0.78 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | N-Channel | MOSFET (Metal Oxide) | 20 V | 12A (Ta) | 2.5V, 10V | 8mOhm @ 12A, 10V | 1.2V @ 250µA | 58.3 nC @ 10 V | ±12V | 2555 pF @ 10 V | - | 2W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
| |
|
PJQ4463AP-AU_R2_000A160V P-CHANNEL ENHANCEMENT MODE M |
2163 | 0.83 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | P-Channel | MOSFET (Metal Oxide) | 60 V | 4.2A (Ta) | 4.5V, 10V | 68mOhm @ 6A, 10V | 2.5V @ 250µA | 17 nC @ 10 V | ±20V | 879 pF @ 30 V | - | 2.1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
| |
|
PJQ5444-AU_R2_000A140V N-CHANNEL ENHANCEMENT MODE M |
3373 | 0.78 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | N-Channel | MOSFET (Metal Oxide) | 40 V | 12.7A (Ta), 70A (Tc) | 4.5V, 10V | 6.5mOhm @ 20A, 10V | 2.5V @ 250µA | 17 nC @ 4.5 V | ±20V | 1759 pF @ 25 V | - | 2.4W (Ta), 100W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
Таблицы данных |
|
FDD6630AMOSFET N-CH 30V 21A TO252 |
2375 | 0.78 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | PowerTrench® | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 21A (Ta) | 4.5V, 10V | 35mOhm @ 7.6A, 10V | 3V @ 250µA | 7 nC @ 5 V | ±20V | 462 pF @ 15 V | - | 28W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount |
|
Таблицы данных |
|
ZXMP4A57E6QTAMOSFET BVDSS: 31V~40V SOT26 T&R |
3757 | 0.30 |
ДобавитьРасследования |
Tape & Reel (TR) | Automotive, AEC-Q101 | Active | P-Channel | MOSFET (Metal Oxide) | 40 V | 2.9A (Ta) | 4.5V, 10V | 80mOhm @ 4A, 10V | 3V @ 250µA | 15.8 nC @ 10 V | ±20V | 833 pF @ 20 V | - | 1.1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
SQJA64EP-T1_BE3N-CHANNEL 60-V (D-S) 175C MOSFET |
3659 | 0.76 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Automotive, AEC-Q101, TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 15A (Tc) | 10V | 32mOhm @ 4A, 10V | 3.5V @ 250µA | 12 nC @ 10 V | ±20V | 670 pF @ 25 V | - | 45W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
| |
|
PJQ5461A-AU_R2_000A160V P-CHANNEL ENHANCEMENT MODE M |
3026 | 0.79 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | P-Channel | MOSFET (Metal Oxide) | 60 V | 3.2A (Ta), 11.5A (Tc) | 4.5V, 10V | 110mOhm @ 6A, 10V | 2.5V @ 250µA | 10 nC @ 10 V | ±20V | 785 pF @ 30 V | - | 2W (Ta), 26W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
MCQ18N03-TPN-CHANNEL MOSFET,SOP-8 |
2152 | 0.79 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 18A | 4.5V, 10V | 5mOhm @ 18A, 10V | 2.5V @ 250µA | 42 nC @ 10 V | ±20V | 1950 pF @ 15 V | - | 2.5W | -55°C ~ 175°C (TJ) | Surface Mount |
|
Таблицы данных |
|
SSM6J808R,LXHFAUTO AEC-Q SS MOS P-CH LOGIC-LEV |
3683 | 0.80 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Automotive, AEC-Q101 | Active | P-Channel | MOSFET (Metal Oxide) | 40 V | 7A (Ta) | 4V, 10V | 35mOhm @ 2.5A, 10V | 2V @ 100µA | 24.2 nC @ 10 V | +10V, -20V | 1020 pF @ 10 V | - | 1.5W (Ta) | 150°C | Surface Mount |
|
Таблицы данных |
.jpg)
|
SI2323DS-T1-BE3P-CHANNEL 20-V (D-S) MOSFET |
3957 | 0.77 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | P-Channel | MOSFET (Metal Oxide) | 20 V | 3.7A (Ta) | 1.8V, 4.5V | 39mOhm @ 4.7A, 4.5V | 1V @ 250µA | 19 nC @ 4.5 V | ±8V | 1020 pF @ 10 V | - | 750mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
| |
|
RM80N60LDMOSFET N-CHANNEL 60V 80A TO252-2 |
2737 | 0.31 |
ДобавитьРасследования |
Tape & Reel (TR) | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 80A (Tc) | 10V | 8.5mOhm @ 20A, 10V | 4V @ 250µA | - | ±20V | 4000 pF @ 30 V | - | 110W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
| |
|
RM10N100S8MOSFET N-CHANNEL 100V 10A 8SOP |
3813 | 0.31 |
ДобавитьРасследования |
Tape & Reel (TR) | - | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 10A (Ta) | 4.5V, 10V | 14mOhm @ 10A, 10V | 2.5V @ 250µA | - | ±20V | 1640 pF @ 50 V | - | 3.1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
DMNH6042SPSQ-13MOSFET N-CH 60V 24A PWRDI5060-8 |
2854 | 0.81 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | N-Channel | MOSFET (Metal Oxide) | 60 V | 24A (Tc) | 4.5V, 10V | 50mOhm @ 5.1A, 10V | 3V @ 250µA | 8.8 nC @ 10 V | ±20V | 584 pF @ 25 V | - | 2.9W (Ta) | -55°C ~ 175°C (TJ) | Surface Mount |
| |
|
PJD14P10A_L2_00001100V P-CHANNEL MOSFET |
2831 | 0.81 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Active | P-Channel | MOSFET (Metal Oxide) | 100 V | 2.5A (Ta), 14A (Tc) | 4.5V, 10V | 140mOhm @ 7A, 10V | 3V @ 250µA | 40.7 nC @ 10 V | ±20V | 2298 pF @ 30 V | - | 2W (Ta), 60W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
SQS405CENW-T1_GE3AUTOMOTIVE P-CHANNEL 12 V (D-S) |
3592 | 0.79 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Automotive, AEC-Q101, TrenchFET® | Active | P-Channel | MOSFET (Metal Oxide) | 12 V | 16A (Tc) | 2.5V, 4.5V | 15mOhm @ 13.5A, 4.5V | 1V @ 250µA | 81 nC @ 8 V | ±8V | 3050 pF @ 6 V | - | 39W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
|
Таблицы данных |
|
SQJA70EP-T1_BE3N-CHANNEL 100-V (D-S) 175C MOSFE |
3466 | 0.79 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Automotive, AEC-Q101, TrenchFET® | Active | N-Channel | MOSFET (Metal Oxide) | 100 V | 14.7A (Tc) | 10V | 95mOhm @ 4A, 10V | 3.5V @ 250µA | 7 nC @ 10 V | ±20V | 220 pF @ 25 V | - | 27W (Tc) | -55°C ~ 175°C (TJ) | Surface Mount |
| |
|
RM002N30DFMOSFET N-CHANNEL 30V 85A 8DFN |
2557 | 0.32 |
ДобавитьРасследования |
Tape & Reel (TR) | - | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 85A (Tc) | 4.5V, 10V | 2.4mOhm @ 30A, 10V | 2.5V @ 250µA | - | ±20V | 4345 pF @ 15 V | - | 187W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
