Грузовой вагон ( )| Таблицы данных | Фотографии | Производитель. Часть # | Акции | Цены | А | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Таблицы данных |
|
IRL3103D2PBFMOSFET N-CH 30V 54A TO220AB |
2711 | 0.00 |
ДобавитьРасследования |
Tube | FETKY™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 54A (Tc) | 4.5V, 10V | 14mOhm @ 32A, 10V | 1V @ 250µA | 44 nC @ 4.5 V | ±16V | 2300 pF @ 25 V | - | 2W (Ta), 70W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFZ48NLPBFMOSFET N-CH 55V 64A TO262 |
2081 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 64A (Tc) | 10V | 14mOhm @ 32A, 10V | 4V @ 250µA | 81 nC @ 10 V | ±20V | 1970 pF @ 25 V | - | 3.8W (Ta), 130W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRL2203NLPBFMOSFET N-CH 30V 116A TO262 |
2274 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 116A (Tc) | 4.5V, 10V | 7mOhm @ 60A, 10V | 3V @ 250µA | 60 nC @ 4.5 V | ±16V | 3290 pF @ 25 V | - | 3.8W (Ta), 180W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRL3705NLPBFMOSFET N-CH 55V 89A TO262 |
3129 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 89A (Tc) | 4V, 10V | 10mOhm @ 46A, 10V | 2V @ 250µA | 98 nC @ 5 V | ±16V | 3600 pF @ 25 V | - | 3.8W (Ta), 170W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFB42N20DPBFMOSFET N-CH 200V 44A TO220AB |
2820 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 200 V | 44A (Tc) | 10V | 55mOhm @ 26A, 10V | 5.5V @ 250µA | 140 nC @ 10 V | ±30V | 3430 pF @ 25 V | - | 2.4W (Ta), 330W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFB17N60KPBFMOSFET N-CH 600V 17A TO220AB |
2716 | 0.00 |
ДобавитьРасследования |
Tube | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 17A (Tc) | 10V | 420mOhm @ 10A, 10V | 5V @ 250µA | 99 nC @ 10 V | ±30V | 2700 pF @ 25 V | - | 340W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFBA1405PPBFMOSFET N-CH 55V 174A SUPER-220 |
3118 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 174A (Tc) | 10V | 5mOhm @ 101A, 10V | 4V @ 250µA | 260 nC @ 10 V | ±20V | 5480 pF @ 25 V | - | 330W (Tc) | -40°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFBA22N50APBFMOSFET N-CH 500V 24A SUPER-220 |
3444 | 0.00 |
ДобавитьРасследования |
Tube | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 500 V | 24A (Tc) | 10V | 230mOhm @ 13.8A, 10V | 4V @ 250µA | 115 nC @ 10 V | ±30V | 3400 pF @ 25 V | - | 340W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRL3803LPBFMOSFET N-CH 30V 140A TO262 |
3863 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 140A (Tc) | 4.5V, 10V | 6mOhm @ 71A, 10V | 1V @ 250µA | 140 nC @ 4.5 V | ±16V | 5000 pF @ 25 V | - | 3.8W (Ta), 200W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRLU3714ZPBFMOSFET N-CH 20V 37A I-PAK |
2984 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 37A (Tc) | 4.5V, 10V | 15mOhm @ 15A, 10V | 2.55V @ 250µA | 7.1 nC @ 4.5 V | ±20V | 560 pF @ 10 V | - | 35W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
;;3.jpg)
|
IRFU3704PBFMOSFET N-CH 20V 75A IPAK |
3332 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 75A (Tc) | 10V | 9.5mOhm @ 15A, 10V | 3V @ 250µA | 19 nC @ 4.5 V | ±20V | 1996 pF @ 10 V | - | 90W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRLU3714PBFMOSFET N-CH 20V 36A I-PAK |
3707 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 36A (Tc) | 4.5V, 10V | 20mOhm @ 18A, 10V | 3V @ 250µA | 9.7 nC @ 4.5 V | ±20V | 670 pF @ 10 V | - | 47W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFU120ZPBFMOSFET N-CH 100V 8.7A IPAK |
2540 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 8.7A (Tc) | 10V | 190mOhm @ 5.2A, 10V | 4V @ 250µA | 10 nC @ 10 V | ±20V | 310 pF @ 25 V | - | 35W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRLU120PBFMOSFET N-CH 100V 7.7A TO251AA |
3580 | 0.00 |
ДобавитьРасследования |
Tube | - | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 7.7A (Tc) | 4V, 5V | 270mOhm @ 4.6A, 5V | 2V @ 250µA | 12 nC @ 5 V | ±10V | 490 pF @ 25 V | - | 2.5W (Ta), 42W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRLU4343PBFMOSFET N-CH 55V 26A I-PAK |
2277 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 26A (Tc) | 4.5V, 10V | 50mOhm @ 4.7A, 10V | 1V @ 250µA | 42 nC @ 10 V | ±20V | 740 pF @ 50 V | - | 79W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRLU7821PBFMOSFET N-CH 30V 65A I-PAK |
2646 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 65A (Tc) | 4.5V, 10V | 10mOhm @ 15A, 10V | 1V @ 250µA | 14 nC @ 4.5 V | ±20V | 1030 pF @ 15 V | - | 75W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFU3504ZPBFMOSFET N-CH 40V 42A IPAK |
2399 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 40 V | 42A (Tc) | 10V | 9mOhm @ 42A, 10V | 4V @ 250µA | 45 nC @ 10 V | ±20V | 1510 pF @ 25 V | - | 90W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFU2905ZPBFMOSFET N-CH 55V 42A IPAK |
2059 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 55 V | 42A (Tc) | 10V | 14.5mOhm @ 36A, 10V | 4V @ 250µA | 44 nC @ 10 V | ±20V | 1380 pF @ 25 V | - | 110W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRFU3711PBFMOSFET N-CH 20V 100A IPAK |
3097 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 100A (Tc) | 4.5V, 10V | 6.5mOhm @ 15A, 10V | 3V @ 250µA | 44 nC @ 4.5 V | ±20V | 2980 pF @ 10 V | - | 2.5W (Ta), 120W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRLU7833PBFMOSFET N-CH 30V 140A I-PAK |
3307 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 140A (Tc) | 4.5V, 10V | 4.5mOhm @ 15A, 10V | 2.3V @ 250µA | 50 nC @ 4.5 V | ±20V | 4010 pF @ 15 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
Запрос котировок
