Грузовой вагон ( )| Таблицы данных | Фотографии | Производитель. Часть # | Акции | Цены | А | Packaging | Series | ProductStatus | FETType | Technology | DraintoSourceVoltage(Vdss) | Current-ContinuousDrain(Id)@25°C | DriveVoltage(MaxRdsOnMinRdsOn) | RdsOn(Max)@IdVgs | Vgs(th)(Max)@Id | GateCharge(Qg)(Max)@Vgs | Vgs(Max) | InputCapacitance(Ciss)(Max)@Vds | FETFeature | PowerDissipation(Max) | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Таблицы данных |
|
SPP18P06PHKSA1MOSFET P-CH 60V 18.7A TO220-3 |
3484 | 0.00 |
ДобавитьРасследования |
Tube | SIPMOS® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 60 V | 18.7A (Ta) | 10V | 130mOhm @ 13.2A, 10V | 4V @ 1mA | 28 nC @ 10 V | ±20V | 860 pF @ 25 V | - | 81.1W (Ta) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
SPP20N60S5MOSFET N-CH 650V 20A TO220-3 |
3438 | 0.00 |
ДобавитьРасследования |
Tube | CoolMOS™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 650 V | 20A (Tc) | 10V | 190mOhm @ 13A, 10V | 5.5V @ 1mA | 103 nC @ 10 V | ±20V | 3000 pF @ 25 V | - | 208W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
Таблицы данных |
|
BSS119E6327MOSFET N-CH 100V 170MA SOT23-3 |
2735 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 170mA (Ta) | 4.5V, 10V | 6Ohm @ 170mA, 10V | 2.3V @ 50µA | 2.5 nC @ 10 V | ±20V | 78 pF @ 25 V | - | 360mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSP123L6327HTSA1MOSFET N-CH 100V 370MA SOT223-4 |
3363 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 370mA (Ta) | 2.8V, 10V | 6Ohm @ 370mA, 10V | 1.8V @ 50µA | 2.4 nC @ 10 V | ±20V | 70 pF @ 25 V | - | 1.79W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSP129E6327MOSFET N-CH 240V 350MA SOT223-4 |
2609 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 240 V | 350mA (Ta) | 0V, 10V | 6Ohm @ 350mA, 10V | 1V @ 108µA | 5.7 nC @ 5 V | ±20V | 108 pF @ 25 V | Depletion Mode | 1.8W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSP295E6327MOSFET N-CH 60V 1.8A SOT223-4 |
2955 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 1.8A (Ta) | 4.5V, 10V | 300mOhm @ 1.8A, 10V | 1.8V @ 400µA | 17 nC @ 10 V | ±20V | 368 pF @ 25 V | - | 1.8W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSP296E6327MOSFET N-CH 100V 1.1A SOT223-4 |
2949 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 1.1A (Ta) | 4.5V, 10V | 700mOhm @ 1.1A, 10V | 1.8V @ 400µA | 17.2 nC @ 10 V | ±20V | 364 pF @ 25 V | - | 1.79W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSP315P-E6327MOSFET P-CH 60V 1.17A SOT223-4 |
3881 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 60 V | 1.17A (Ta) | 4.5V, 10V | 800mOhm @ 1.17A, 10V | 2V @ 160µA | 7.8 nC @ 10 V | ±20V | 160 pF @ 25 V | - | 1.8W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSP88E6327MOSFET N-CH 240V 350MA SOT223-4 |
263394 | 0.19 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Bulk | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 240 V | 350mA (Ta) | 2.8V, 4.5V | 6Ohm @ 350mA, 10V | 1.4V @ 108µA | 6.8 nC @ 10 V | ±20V | 95 pF @ 25 V | - | 1.7W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSS123E6327MOSFET N-CH 100V 170MA SOT23-3 |
2557 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 100 V | 170mA (Ta) | 4.5V, 10V | 6Ohm @ 170mA, 10V | 1.8V @ 50µA | 2.67 nC @ 10 V | ±20V | 69 pF @ 25 V | - | 360mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSS131E6327MOSFET N-CH 240V 110MA SOT23-3 |
3140 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 240 V | 110mA (Ta) | 4.5V, 10V | 14Ohm @ 100mA, 10V | 1.8V @ 56µA | 3.1 nC @ 10 V | ±20V | 77 pF @ 25 V | - | 360mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSS138N-E6327MOSFET N-CH 60V 230MA SOT23-3 |
2031 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 60 V | 230mA (Ta) | 4.5V, 10V | 3.5Ohm @ 230mA, 10V | 1.4V @ 250µA | 1.4 nC @ 10 V | ±20V | 41 pF @ 25 V | - | 360mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSS84P-E6327MOSFET P-CH 60V 170MA SOT23-3 |
2735 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | P-Channel | MOSFET (Metal Oxide) | 60 V | 170mA (Ta) | 4.5V, 10V | 8Ohm @ 170mA, 10V | 2V @ 20µA | 1.5 nC @ 10 V | ±20V | 19 pF @ 25 V | - | 360mW (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
BSS87E6327MOSFET N-CH 240V 260MA SOT89-4 |
3581 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | SIPMOS® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 240 V | 260mA (Ta) | 4.5V, 10V | 6Ohm @ 260mA, 10V | 1.8V @ 108µA | 5.5 nC @ 10 V | ±20V | 97 pF @ 25 V | - | 1W (Ta) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
SPD07N60S5MOSFET N-CH 600V 7.3A TO252-3 |
2719 | 0.64 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT),Bulk | CoolMOS™ | Obsolete | N-Channel | MOSFET (Metal Oxide) | 600 V | 7.3A (Tc) | 10V | 600mOhm @ 4.6A, 10V | 5.5V @ 350µA | 35 nC @ 10 V | ±20V | 970 pF @ 25 V | - | 83W (Tc) | -55°C ~ 150°C (TJ) | Surface Mount |
|
Таблицы данных |
|
ZXM64P035L3MOSFET P-CH 35V 3.3A/12A TO220-3 |
3700 | 0.00 |
ДобавитьРасследования |
Bulk | - | Obsolete | P-Channel | MOSFET (Metal Oxide) | 35 V | 3.3A (Ta), 12A (Tc) | 4.5V, 10V | 75mOhm @ 2.4A, 10V | 1V @ 250µA | 46 nC @ 10 V | ±20V | 825 pF @ 25 V | - | 1.5W (Ta), 20W (Tc) | -55°C ~ 150°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRLU7833MOSFET N-CH 30V 140A I-PAK |
3757 | 0.00 |
ДобавитьРасследования |
Tube | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 140A (Tc) | 4.5V, 10V | 4.5mOhm @ 15A, 10V | 2.3V @ 250µA | 50 nC @ 4.5 V | ±20V | 4010 pF @ 15 V | - | 140W (Tc) | -55°C ~ 175°C (TJ) | Through Hole |
|
Таблицы данных |
|
IRF6601MOSFET N-CH 20V 26A DIRECTFET |
3686 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 26A (Ta), 85A (Tc) | 4.5V, 10V | 3.8mOhm @ 26A, 10V | 2.2V @ 250µA | 45 nC @ 4.5 V | ±20V | 3440 pF @ 15 V | - | 3.6W (Ta), 42W (Tc) | - | Surface Mount |
|
Таблицы данных |
|
IRF6602MOSFET N-CH 20V 11A DIRECTFET |
3160 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 20 V | 11A (Ta), 48A (Tc) | 4.5V, 10V | 13mOhm @ 11A, 10V | 2.3V @ 250µA | 18 nC @ 4.5 V | ±20V | 1420 pF @ 10 V | - | 2.3W (Ta), 42W (Tc) | - | Surface Mount |
|
Таблицы данных |
|
IRF6603MOSFET N-CH 30V 27A DIRECTFET |
2741 | 0.00 |
ДобавитьРасследования |
Tape & Reel (TR),Cut Tape (CT) | HEXFET® | Obsolete | N-Channel | MOSFET (Metal Oxide) | 30 V | 27A (Ta), 92A (Tc) | 4.5V, 10V | 3.4mOhm @ 25A, 10V | 2.5V @ 250µA | 72 nC @ 4.5 V | +20V, -12V | 6590 pF @ 15 V | - | 3.6W (Ta), 42W (Tc) | -40°C ~ 150°C (TJ) | Surface Mount |
Запрос котировок
