Грузовой вагон ( )| Таблицы данных | Фотографии | Производитель. Часть # | Акции | Цены | А | Package/Case | Packaging | Series | ProductStatus | SwitchCircuit | Multiplexer/DemultiplexerCircuit | NumberofCircuits | On-StateResistance(Max) | Channel-to-ChannelMatching(ΔRon) | Voltage-SupplySingle(V+) | Voltage-SupplyDual(V±) | SwitchTime(TonToff)(Max) | -3dbBandwidth | ChargeInjection | ChannelCapacitance(CS(off)CD(off)) | Current-Leakage(IS(off))(Max) | Crosstalk | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Таблицы данных |
|
CD4051BCMXIC MUX/DEMUX 8X1 16SOIC |
3130 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Obsolete | - | 8:1 | 1 | 240Ohm | 5Ohm | 5V ~ 15V | ±2.5V ~ 7.5V | 320ns, 150ns | 40MHz | - | - | 50nA | -40dB @ 3MHz | -55°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
|
CD4052BCMXIC MUX/DEMUX DUAL 4X1 16SOIC |
2673 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Obsolete | SP4T | 4:1 | 2 | 240Ohm | 5Ohm | 5V ~ 15V | ±2.5V ~ 7.5V | 320ns, 150ns | 40MHz | - | - | 50nA | -40dB @ 3MHz | -55°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
|
CD4053BCMXIC MUX/DEMUX TRIPLE 2X1 16SOIC |
3975 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Obsolete | SPDT | 2:1 | 3 | 240Ohm | 5Ohm | 5V ~ 15V | ±2.5V ~ 7.5V | 320ns, 150ns | 40MHz | - | - | 50nA | -40dB @ 3MHz | -55°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
|
MM74HC4051MXIC MUX/DEMUX 8X1 16SOIC |
3856 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Obsolete | - | 8:1 | 1 | 100Ohm | 15Ohm | 2V ~ 6V | ±2V ~ 6V | 41ns, 32ns | 35MHz | - | 5pF, 90pF | 100nA | -50dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
ADG742BKSZ5-REELIC SWITCH SPST SC70-5 |
3354 | 0.00 |
ДобавитьРасследования |
5-TSSOP, SC-70-5, SOT-353 | Tape & Reel (TR) | - | Obsolete | SPST - NC | 1:1 | 1 | 3Ohm | - | 1.8V ~ 5.5V | - | 12ns, 8ns (Typ) | 200MHz | 5pC | 17pF, 17pF | 250pA | - | -40°C ~ 85°C (TA) | Surface Mount |
| |
|
ADG1209YCPZ-REELIC MULTIPLEXER DUAL 4X1 16LFCSP |
3203 | 0.00 |
ДобавитьРасследования |
16-VQFN Exposed Pad, CSP | Tape & Reel (TR) | - | Obsolete | SP4T | 4:1 | 2 | 200Ohm | 3.5Ohm | 5V ~ 16.5V | ±5V ~ 16.5V | 95ns, 100ns | 550MHz | 0.4pC | 1.5pF, 4.5pF | 100pA | -85dB @ 1MHz | -40°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
|
HI9P0509-5Z96IC MULTIPLEXER DUAL 4X1 16SOIC |
3952 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR) | - | Obsolete | SP4T | 4:1 | 2 | 400Ohm | 20Ohm | - | ±15V | 250ns, 250ns (Typ) | - | - | 10pF, 12pF | 30pA (Typ) | - | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
ISL43L710IUZIC SWITCH DUAL SPST 8MSOP |
2153 | 0.00 |
ДобавитьРасследования |
8-TSSOP, 8-MSOP (0.118, 3.00mm Width) | Tube | - | Obsolete | SPST - NO | 1:1 | 2 | 250mOhm | 5mOhm | 1.65V ~ 3.6V | - | 25ns, 25ns | - | -125pC | 182pF, 182pF | 3nA | -94dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
ISL43L710IUZ-TIC SWITCH DUAL SPST 8MSOP |
2909 | 0.00 |
ДобавитьРасследования |
8-TSSOP, 8-MSOP (0.118, 3.00mm Width) | Tape & Reel (TR) | - | Obsolete | SPST - NO | 1:1 | 2 | 250mOhm | 5mOhm | 1.65V ~ 3.6V | - | 25ns, 25ns | - | -125pC | 182pF, 182pF | 3nA | -94dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
DG508ADYIC MULTIPLEXER 8X1 16SOIC |
141 | 3.74 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tube,Tube | - | Obsolete | - | 8:1 | 1 | 450Ohm | 27Ohm | - | ±4.5V ~ 18V | 1.5µs, 1µs | - | - | 5pF, 25pF | 1nA | - | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
HCF4051BM1IC MUX/DEMUX 8X1 16SOIC |
2087 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tube | - | Obsolete | - | 8:1 | 1 | 280Ohm | 5Ohm | 3V ~ 20V | - | - | 60MHz | - | 0.2pF, 5pF | 100nA | -40dB @ 3MHz | -55°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
|
HCF4097M013TRIC MUX 8X1 240 OHM 24SOIC |
3708 | 0.00 |
ДобавитьРасследования |
24-SOIC (0.295, 7.50mm Width) | Tape & Reel (TR) | - | Obsolete | - | 8:1 | 2 | 240Ohm | 5Ohm | 3V ~ 20V | - | - | - | - | 0.2pF, 5pF | 100µA | -40dB @ 1MHz | -55°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
.jpg)
|
M74HC4852MWRIC MUX/DEMUX DUAL 4X1 16SOIC |
2277 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.295, 7.50mm Width) | Tape & Reel (TR) | - | Obsolete | SP4T | 4:1 | 2 | 195Ohm | 3Ohm | 2V ~ 6V | - | - | - | - | 6.7pF, 22pF | 100nA | - | -55°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
|
STG3684ADTRIC SWITCH DUAL SPDT 10UFDFN |
2262 | 0.00 |
ДобавитьРасследования |
10-UFDFN Exposed Pad | Tape & Reel (TR) | - | Obsolete | SPDT | 2:1 | 2 | 500mOhm | 100mOhm | 1.65V ~ 4.3V | - | 55ns, 30ns | 55MHz | 49pC | 5pF | 20nA | -72dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
STG3689DTRIC SWITCH DUAL SPDT 10TDFN |
2480 | 0.00 |
ДобавитьРасследования |
10-UFDFN | Tape & Reel (TR) | - | Obsolete | SPDT | 2:1 | 2 | 700mOhm | 600mOhm | 1.65V ~ 4.3V | - | 50ns, 30ns | 85MHz | 44pC | 7pF | 10nA | -76dB @ 100kHz | -55°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
|
STG4159BJRIC SWITCH SPDT 7CLIPCHIP |
3612 | 0.00 |
ДобавитьРасследования |
7-WFBGA, FCBGA | Tape & Reel (TR) | - | Obsolete | SPDT | 2:1 | 1 | 300mOhm | 3mOhm | 1.65V ~ 4.8V | - | 38ns, 17ns | 28MHz | 140pC | 30pF | 30nA | -69dB @ 100kHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
CD74HC4051MDREPIC MUX/DEMUX 8X1 16SOIC |
2621 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Obsolete | - | 8:1 | 1 | 130Ohm | 5Ohm | 2V ~ 6V | ±1V ~ 5V | - | 180MHz | - | 25pF | 400nA | - | -55°C ~ 125°C (TA) | Surface Mount |
|
Таблицы данных |
|
SN74LV4052ATDREPIC MULTIPLEXER DUAL 4X1 16SOIC |
2271 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Obsolete | SP4T | 4:1 | 2 | 100Ohm | 20Ohm (Max) | 2V ~ 5.5V | - | 18ns, 18ns | 50MHz | - | - | 1µA | -45dB @ 1MHz | -40°C ~ 105°C (TA) | Surface Mount |
|
Таблицы данных |
|
SN74LV4053ATDREPIC MUX/DEMUX TRIPLE 2X1 16SOIC |
3490 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.154, 3.90mm Width) | Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | - | Obsolete | SPDT | 2:1 | 3 | 75Ohm | 1.3Ohm | 2V ~ 5.5V | - | 14ns, 14ns | 50MHz | - | 0.5pF, 8.2pF | 100nA | -45dB @ 1MHz | -40°C ~ 105°C (TA) | Surface Mount |
|
Таблицы данных |
|
ADV3000ASTZIC HDMI/DVI SWITCH 3.1 80LQFP |
7341 | 7.59 |
ДобавитьРасследования |
80-LQFP | Tray | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount |
