Грузовой вагон ( )| Таблицы данных | Фотографии | Производитель. Часть # | Акции | Цены | А | Package/Case | Packaging | Series | ProductStatus | SwitchCircuit | Multiplexer/DemultiplexerCircuit | NumberofCircuits | On-StateResistance(Max) | Channel-to-ChannelMatching(ΔRon) | Voltage-SupplySingle(V+) | Voltage-SupplyDual(V±) | SwitchTime(TonToff)(Max) | -3dbBandwidth | ChargeInjection | ChannelCapacitance(CS(off)CD(off)) | Current-Leakage(IS(off))(Max) | Crosstalk | OperatingTemperature | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Таблицы данных |
|
PI5A126WIC SWITCH DUAL SPST 8SOIC |
3561 | 0.00 |
ДобавитьРасследования |
8-SOIC (0.154, 3.90mm Width) | Bag | - | Obsolete | SPST - NO | 1:1 | 2 | 10Ohm | 200mOhm | 2V ~ 6V | - | 15ns, 7ns | 326MHz | 1.6pC | 5.5pF, 5.5pF | 200pA (Typ) | -43dB @ 10MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PI5A127WIC SWITCH DUAL SPST 8SOIC |
3382 | 0.00 |
ДобавитьРасследования |
8-SOIC (0.154, 3.90mm Width) | Bag | - | Obsolete | SPST - NC | 1:1 | 2 | 10Ohm | 200mOhm | 2V ~ 6V | - | 15ns, 7ns | 326MHz | 1.6pC | 5.5pF, 5.5pF | 200pA (Typ) | -43dB @ 10MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS301CPAIC SWITCH SPST 8DIP |
2229 | 0.00 |
ДобавитьРасследования |
8-DIP (0.300, 7.62mm) | Tube | - | Obsolete | SPST - NO | 1:1 | 1 | 60Ohm | 800mOhm | 2.5V ~ 16 V | - | 150ns, 100ns | - | 1pC | 9pF, 9pF | 100pA | -85dB @ 1MHz | -40°C ~ 85°C (TA) | Through Hole |
|
Таблицы данных |
|
PS301CUAIC SPST ANALOG SW 8-MSOP |
2997 | 0.00 |
ДобавитьРасследования |
8-TSSOP, 8-MSOP (0.118, 3.00mm Width) | Tube | - | Obsolete | SPST - NO | 1:1 | 1 | 60Ohm | 800mOhm | 2.5V ~ 16 V | - | 150ns, 100ns | - | 1pC | 9pF, 9pF | 100pA | -85dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS383EPEIC SWITCH DUAL SPDT 16DIP |
2298 | 0.00 |
ДобавитьРасследования |
16-DIP (0.300, 7.62mm) | Tube | - | Obsolete | SPDT | 2:1 | 2 | 30Ohm | 200mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | - | 2pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Through Hole |
|
Таблицы данных |
|
PS383ESEIC SWITCH DUAL SPDT 16SOIC |
2500 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.295, 7.50mm Width) | Tube | - | Obsolete | SPDT | 2:1 | 2 | 30Ohm | 200mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | - | 2pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS385ESEIC SWITCH DUAL DPST 16SOIC |
3605 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.295, 7.50mm Width) | Tube | - | Obsolete | DPST - NO | 2:1 | 2 | 30Ohm | 200mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | - | 2pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS391EPEIC SWITCH QUAD SPST 16DIP |
2525 | 0.00 |
ДобавитьРасследования |
16-DIP (0.300, 7.62mm) | Tray | - | Obsolete | SPST - NC | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | 100MHz | 3pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Through Hole |
|
Таблицы данных |
|
PS391ESEIC SWITCH QUAD SPST 16SOIC |
3809 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.295, 7.50mm Width) | Tube | - | Obsolete | SPST - NC | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | 100MHz | 3pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS392CPEIC SWITCH QUAD SPST 16DIP |
3472 | 0.00 |
ДобавитьРасследования |
16-DIP (0.300, 7.62mm) | Tray | - | Obsolete | SPST - NO | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | 100MHz | 3pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | 0°C ~ 70°C (TA) | Through Hole |
|
Таблицы данных |
|
PS392CSEIC SWITCH QUAD SPST 16SOIC |
3932 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.295, 7.50mm Width) | Tube | - | Obsolete | SPST - NO | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | 100MHz | 3pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | 0°C ~ 70°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS392EPEIC SWITCH QUAD SPST 16DIP |
3245 | 0.00 |
ДобавитьРасследования |
16-DIP (0.300, 7.62mm) | - | - | Obsolete | SPST - NO | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | 100MHz | 3pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Through Hole |
|
Таблицы данных |
|
PS392ESEIC SWITCH QUAD SPST 16SOIC |
2429 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.295, 7.50mm Width) | Tube | - | Obsolete | SPST - NO | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | 100MHz | 3pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS393EPEIC SWITCH QUAD SPST 16DIP |
2410 | 0.00 |
ДобавитьРасследования |
16-DIP (0.300, 7.62mm) | Tray | - | Obsolete | SPST - NO/NC | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | 100MHz | 3pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Through Hole |
|
Таблицы данных |
|
PS393ESEIC SWITCH QUAD SPST 16SOIC |
2762 | 0.00 |
ДобавитьРасследования |
16-SOIC (0.295, 7.50mm Width) | Tube | - | Obsolete | SPST - NO/NC | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | 100MHz | 3pC | 12pF, 12pF | 100pA | -90dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS4066ACSDIC QUAD SPST ANALOG SW 14-SOIC |
2579 | 0.00 |
ДобавитьРасследования |
14-SOIC (0.154, 3.90mm Width) | Tube | - | Obsolete | SPST - NO | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 16V | - | 100ns, 75ns | 100MHz | 2pC | 9pF, 9pF | 100pA | -86dB @ 1MHz | 0°C ~ 70°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS4066AEEEIC QUAD SPST ANALOG SW 16-QSOP |
2608 | 0.00 |
ДобавитьРасследования |
16-SSOP (0.154, 3.90mm Width) | Tube | - | Obsolete | SPST - NO | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 16V | - | 100ns, 75ns | 100MHz | 2pC | 9pF, 9pF | 100pA | -86dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
PS4066AESDIC QUAD SPST ANALOG SW 14-SOIC |
3306 | 0.00 |
ДобавитьРасследования |
14-SOIC (0.154, 3.90mm Width) | Tube | - | Obsolete | SPST - NO | 1:1 | 4 | 45Ohm | 500mOhm | 3V ~ 16V | - | 100ns, 75ns | 100MHz | 2pC | 9pF, 9pF | 100pA | -86dB @ 1MHz | -40°C ~ 85°C (TA) | Surface Mount |
|
Таблицы данных |
|
LTC202CJIC SWITCH SPST QUAD 16DIP |
2706 | 0.00 |
ДобавитьРасследования |
16-CDIP (0.300, 7.62mm) | Tube | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Through Hole |
|
Таблицы данных |
|
LTC221CJIC ANLG SWITCH QUAD SPST 16CDIP |
3611 | 0.00 |
ДобавитьРасследования |
16-CDIP (0.300, 7.62mm) | Tube | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Through Hole |
